Putzmeister Concrete Pump Boom Pipe With Weld-on Collars at the end. it can used for boom ,ground pipeline and trck pipelines,they can be supplied in various types and qualities.
Material:Q235, No.20 , ST-52 ,37Mn5, 45Mn2,Thickness From 3mm-10mm or more ,Length:according to the customers’requirement. Normally 1m,2m,3m
Application: in the construction industry, for the Concrete pump placing boom delivery pipe, Concrete pump delivery pipe, Placing boom delivery pipe and Concrete mixing station pipeline in construction industry and so on
Putzmeister Concrete Pump Boom Pipe through Heat treatment ,make pipe more harden than common,Wear resistant layer about 2mm,Boom Pipe’s working life about 25000m³ it is two times than common kind pipe .working pressure about 85Bar.
Putzmeister Boom Pipe connect with casting elbow,snap clamp,and rubber gasket
|
Name |
size | thickness(mm) | length(m) | working pressure |
| Q235 welded pipe | DN125 | 4 | 3 | 85bar |
| DN125 | 4.25 | 3 | 85bar | |
| DN125 | 4.75 | 3 | 85bar | |
| DN125 | 5 | 3 | 85bar | |
| St52 seamless steel pipe | DN125 | 4.5 | 3 | 85bar |
| DN125 | 5 | 3 | 85bar | |
| DN125 | 6 | 3 | 85bar | |
| DN125 | 7.75 | 3 | 85bar | |
| DN125 | 8 | 3 | 85bar | |
| Schwing M/F pipe | DN125 | 4.5 | 3 | 130bar |
| DN125 | 5 | 3 | 130bar | |
| DN125 | 6 | 3 | 130bar | |
| DN125 | 7.8 | 3 | 200bar | |
| Putzmeister ZX pipe | DN125 | 4.5 | 3 | 130bar |
| DN125 | 5 | 3 | 130bar | |
|
DN125 |
6 | 3 | 130bar | |
| DN125 | 7.8 | 3 | 200bar | |
| Single wall pipe | DN125 | 4.5 | 3 | 85bar |
| DN125 | 5 | 3 | 85bar | |
| DN125 | 6 | 3 | 85bar | |
| DN125 | 8 | 3 | 85bar | |
| Twin wall pipe | DN125 | 4.5 | 3 | 85bar |
| DN125 | 5 | 3 | 85bar | |
| DN125 | 8 | 3 | 85bar |
